Portable Precision Weighing in a Compact Case
The unique YA Series weighing pan is integrated right into its carrying case, offering the ultimate combination of portability and protection. Just flip the case open and begin weighing.
Applications
Weighing
Display
Backlit liquid crystal display (LCD)
Operation
2 AAA batteries (included)
Communication
N/A
Construction
ABS housing, stainless steel pan, protective cover
Design Features
Mechanical and software overload/underload protection, auto shut-off
YA GOLD SERIES FEATURES
A hinged cover, sturdy plastic housing, and stainless steel weighing pan protects the small balance from damage.
With an extremely fast stabilization time, your results will appear quickly on the blue backlit LCD display.
Powered by two 'AAA' batteries, a power-saving auto shut-off feature helps to conserve battery life.
Technical Specifications
Model |
YA102 |
YA302 |
YA501 |
Capacity |
100g |
300g |
500g |
Readability |
0.01g |
0.05g |
0.1g |
Linearity |
± 3 d |
||
Repeatability (Std. dev.) |
3 d |
3 d |
3 d |
Weighing Units |
g, oz, ct, gn |
||
Operating Temperature Range |
50°F - 77°F / 10°C - 25°C |
||
Power Requirements |
2 ‘AAA’ batteries (included) |
||
Scale Dimensions |
4.3 x 2.9 x 0.8 in / 110 x 75 x 20 mm |
||
Pan Size |
2.8 x 2.0 in / 70 x 50 mm |
||
Package Dimensions |
5.9 x 3.9 x 1.2 in / 150 x 100 x 30 mm |
