Harry Gestigkeit Digital Heating Multi-Purpose Bath

Score: 5.00 (votes: 2)
No reviews.
SKU Temperature Range Volume Capacity (L) External Dimensions (mm) Weight (In Grams) Price (excluding VAT) Availability Qty To Purchase
Harry Gestigkeit Digital Heating Multi-Purpose Bath PZ26-4 20°C To 400°C 5 310 x 310 6800 £1339.00 1 + -
Harry Gestigkeit Digital Heating Multi-Purpose Bath PZ26-7 20°C To 700°C 5 310 x 310 6800 £1366.00 1 + -

PZ 26-4 is suitable for use as either a Fluid, Air or Sand bath using temperatures of up to 400°C. As bath fillings is is possible to use Oils, Water, Sand or any other filling which will not attack the surface of the bath, which is made out of high-grade, stainless steel  W-No.1.4301.

PZ 26-7 designed for temperatures up to 700°C, offers similar application methods, but solely as a Dry, Air or Sand bath.   Both baths are also well-suited for use as rotary evaporators, heating is provided by a tubular radiator.

The appliances are controlled by means of a microprocessor  PID-Controller in connection with a low-mass sensor. The actual-value temperature is always on view.  The preset temperature can be seen by pushing a button and can also be adjusted with the up/down key.

The housings are composed of stainless steel with spray-painted base.  All appliances are constructed for continuous operation.



can be used as fluid-, oil-, air- or sandbath for continuous operation

Type PZ 26-4 PZ 26-7
Preselected temperatures °C 20..400 20..700
Display   digital
Power W 1200
Voltage V 230
External dimensions mm 310 x 310
Height mm 280
Weight kg 6,8

    • Weight (In Grams)
      6800 g
    • SKU
      PZ26-4
    • UPC/ISBN
      4250027807526
    • Commodity Codes
      84198998
  • Manufacturer
    Harry Gestigkeit GmbH
  • Country of Origin
    Germany
  • Temperature Range
    20°C To 400°C, 20°C To 700°C
  • Volume Capacity (L)
    5, N/A
  • External Dimensions (mm)
    310 x 310, N/A

Accessories
