VT Range – Oil Free Air Compressors
Quality is the primary component built into each Bambi VT Oil Free Compressor.
Bambi’s revolutionary VT range of oil free compressors is available with our innovative air dryer unit. With quality the key word, our oil free, clean & dry air units are class leading and packed with the latest features.
- Soft start valve
- Internally coated receiver
- Air dryer
- After cooler & coalescing filter
- Sequential start
At the heart of the VT range is our all new Vee Twin pump unit with one of the lowest noise levels of any oil free compressor available, made possible by the very latest “tilting piston” technology. Perfect when you demand the highest possible air quality for critical applications; dentistry, scientific laboratories, food packaging, pneumatic controls, hospital ventilators, drink dispensing – and anywhere when low maintenance is essential.
Packed with novel technical features, even the standard models without air dryers are fitted with a “soft start” solenoid valve. This discharges the air pressure in the pump whenever the power is disconnected, protecting the compressor from overload and extending the service life. Anti corrosion, internally coated air receivers are fitted across the range ensuring the air is contamination free.
Every model is available with our innovative Air Dryer unit designed to guarantee “desert dry” air. The multi row, fan assisted after-cooler reduces the air temperature prior to entering the dryer. Dramatically reducing the air temperature enables the integral coalescing filter to collect and remove water droplets as small as 0.01 microns.
In this way we remove 99% moisture content before the desiccant adsorption system powers the dryness right down to -40°c Dewpoint. Constructed from high quality “Inox” stainless steel, the dryer regenerates itself every time the compressor cycles and requires no regular maintenance. An integral downstream HE dust filter removes any residual dust. And, uniquely on this size of compressor, the Duplex units are fitted with a sequential start system which enables these 3.0Hp and 4.0Hp systems to run off a 20 amp single phase power source reducing installation costs and start up load.
So confident are we, that every compressor is protected by a comprehensive warranty extending to 5 years on the air receiver.
-
ManufacturerBambi Air Ltd
-
Country of OriginUnited Kingdom
-
Production Rate l/min120, 175, 220, 300, 350, 440
-
Size of Receiver (L)24, 50, 59, 100
-
Dimensions (cm)63 x 51 x 41, 64 x 52 x 49, 87 x 51 x 41, 87 x 52 x 49, 89 x 51 x 43, 89 x 52 x 52, 82 x 66 x 38, 82 x 66 x 57, 78 x 115 x 42, 78 x 115 x 49, 78 x 115 x 43, 78 x 115 x 52
-
Noise dB(A)72, 74, 76
