Model

EX223

EX423

EX623

EX1103

EX2202

EX4202

EX6202

EX10202

EX6201

EX10201

Automatic Door

—

—

—

—

—

—

—

—

—

—

External Calibration

EX223/E

EX423/E

—

—

EX2202/E

EX4202/E

EX6202/E

—

EX6201/E

—

Approved Model

—

EX423M

—

EX1103M

—

EX4202M

—

EX10202M

—

EX10201M

Capacity (g)

220

420

620

1100

2200

4200

6200

10200

6200

10200

Readability (g)

0.001

0.01

0.1

Verification Interval, Approved Models

—

0.01g

—

0.01g

—

0.1g

—

0.1g

—

0.1g

Class, Approved Models

—

II

—

I

—

II

—

I

—

I

Repeatability (sd.),

≤5% of Full Load (g

0.0008

0.008

0.08

Repeatability (sd.), 5% of Full Load to Full Range (g)

0.001

0.01

0.1

Linearity Deviation, Typical (g)

±0.0006

±0.006

±0.06

Linearity Deviation (g)

±0.002

±0.02

±0.2

Stabilization Time (sec)

≤1.5

≤1

Sensitivity Drift (ppm/°C)

3

5

3

Min-Weight (Typical) (g) (USP, K=2, U=0.10%)

1.6

16

160

Min-Weight (Optimal) (g) (USP, K=2, U=0.10%,

SRP≤0.41d)***

0.82

8.2

82

Min-Weight (Typical) (g) (USP, K=2, U=1%)

0.16

1.6

16

Weighing Applications

Weighing, Percent Weighing, Parts Counting, Check Weighing, Dynamic/Animal Weighing, Filling, Totalization, Formulation, Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, Pipette Adjustment, SQC, Fill Weight Variation

Weighing Units

Gram, Milligram, Kilogram, Carat, Ounce, Ounce Troy, Pound, Pennyweight, Grain, Newton, Momme, Mesghal, Hong Kong Tael, Singapore Tael, Taiwan Tael, Tical, Tola, Baht, Custom Unit 1, Custom Unit 2, Custom Unit 3

Weighing Units, Approved Models

—

mg, g, ct

—

mg, g, ct

—

g, kg, ct

—

g, kg, ct

—

g, kg, ct

Pan Size (mm)

Ø 130 mm

190 × 200 mm

Calibration

All models feature external calibration. Models except for EX…/E feature AutoCal™ internal calibration

Tare Range

To capacity by subtraction

Power Requirements

AC Adapter Input: 100-240 VAC 0.6A 50-60 Hz

Display Type

Full-color VGA graphic display, 4-wire resistive touch screen

Display Size

145 mm (diagonal)

Display Housing (W × H × D)

195 × 90 × 154 mm

Base Housing (W × H × D)

230 × 350 × 393 mm

230 × 98 × 393 mm

Communication

Standard RS232, 2x USB, Optional Ethernet

Operating Temperature Range

10°C to 30°C

Operating Humidity Range

15% to 80% at 30°C decreasing linearly to 50% at 40°C, non-condensing

Storage Conditions

-10°C to 60°C at 10% to 90% relative humidity, non-condensing

Net Weight

6.9 kg

4.3 kg

5 kg

Shipping Weight

9.6 kg

6.8 kg

7.4 kg

Shipping Dimensions

55 × 38.5 × 55.1 cm

55 × 38.5 × 29.1 cm
