InCal™ Model

PR124

PR224

PR223

PR423

PR523

ExCal Model

PR124/E

PR224/E

PR223/E

PR423/E

PR523/E

Approved Model*

PR124M

PR224M

PR223M

PR423M

PR523M

Capacity (g)

120

220

420

520

Readability (g)

0.0001

0.001

Verification Interval (e) (g) (Approved Models)

0.001

0.01

Class (Approved Models)

I

II

Repeatability (STDEV) (g)

0.0001

0.001

Linearity (g)

0.0002

0.002

Stabilization Time (s)

3

2

Sensitivity Temperature Drift (PPM/K)

±3

±8

±3

Typical Minimum Weight USP (USP, K=2, U=0.10%)

200 mg

2 g

Optimized Minimum Weight (USP, U=0.10%, K=2) SRP≤0.41d**

82 mg

0.82 g

Units

Milligram, Gram, Ounce, Carat, Pennyweight, Ounce Troy, Newton, grain

Units (Approved Models)

Milligram, Gram, Carat

Applications

Basic Weighing, Parts Counting, Percent Weighing

Pan Size (Ø)

90 mm

120 mm

Tare Range

To full range by subtraction

Power Supply

Power Input: 100 – 240V ~ 200mA 50 – 60Hz 12 – 18VA

Power Output:12 VDC 0.5A

Assembled Dimensions (W × D × H)

201 × 317 × 303 mm

Communication

RS232

Operating Temperature Range

Operating conditions for ordinary lab application: +10 to 30°C (operability guaranteed between +5 and 40°C)

Storage Temperature Range

Humidity: maximum relative humidity 80% for temperatures up to 30 °C, decreasing linearly to 50% relative humidity at 40 °C

Net Weight

4.5 kg

Shipping Weight

7 kg

Shipping Dimensions (W × D × H)

507 × 387 × 531 mm
