Ohaus Pioneer™ Analytical Balances
ZoomCreated with Sketch.

Ohaus Pioneer™ Analytical Balances

Score: 5.00 (votes: 1)
No reviews.
Ohaus Corporation
SKU Maximum Capacity EC Type Approved Calibration Models Weight (In Grams) Price (excluding VAT) Availability Qty To Purchase
Ohaus Pioneer™ Analytical Balances 30429803 120g No InCal™ - Semi Automatic PX124 4500
£1555.00
£1321.75
17 + -
Ohaus Pioneer™ Analytical Balances 30430010 120g Yes InCal™ - Semi Automatic PX124M 4500
£1765.00
£1500.25
1 + -
Ohaus Pioneer™ Analytical Balances 30429810 120g No Not Applicable PX124/E 4500
£1360.00
£1156.00
1 + -
Ohaus Pioneer™ Analytical Balances 30429804 220g No InCal™ - Semi Automatic PX224 4500
£1685.00
£1432.25
42 + -
Ohaus Pioneer™ Analytical Balances 30430013 220g Yes InCal™ - Semi Automatic PX224M 4500
£1860.00
£1581.00
2 + -
Ohaus Pioneer™ Analytical Balances 30429811 220g No Not Applicable PX224/E 4500
£1490.00
£1266.50
8 + -
Combining Economy and High Performance for Essential Weighing

Pioneer PX combines essential weighing functionality with competitive performance, offering high accuracy and repeatability for applications in laboratory, industrial and education settings. The PX is affordably priced, and intuitively designed for intelligent operation with a second-line display for additional information, and USB and RS232 connectivity for easy communication.

Applications

Basic Weighing, Parts Counting, Percent Weighing, Animal Weighing, Density Determination

Display

Backlit Liquid Crystal Display (LCD); Second line display for additional information or guidance (dot matrix)

Operation

AC adapter (included)

Communication

RS232 and USB device (included); GLP/GMP data output with real-time clock

Construction

Metal base, plastic top housing, removable stainless steel pan, glass draft shield, integrated weigh-below-hook, security bracket, calibration lock, and in-use cover

Design Features

User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, user-selectable communication settings, and data print options, user-definable project, and user IDs, software overload/underload indicator, stability indicator, four operating languages
The PX offers high accuracy and repeatability for essential weighing applications in laboratory, industrial and education settings at an economical price point.
Featuring a cast metal lower housing, sub-pan, and stainless steel weighing pan, the PX is durably constructed for versatile, long-term use.
The PX features a second line display for additional information or guidance, a static removal bar for convenient grounding, and USB and RS232 connectivity for easy communication.
    • Weight (In Grams)
      4500 g
    • SKU
      30429803
    • UPC/ISBN
      6971629530596
    • Commodity Codes
      9016001000
  • Manufacturer
    Ohaus Corporation
  • Country of Origin
    China
  • Maximum Capacity
    120g, 220g
  • Readability
    0,1mg
  • Pan Size
    Ø 90mm
  • Calibration
    InCal™ - Semi Automatic, Not Applicable
  • Models
    PX124, PX124M, PX124/E, PX224, PX224M, PX224/E
Full Specifications

InCal™ Model

PX125D*

PX85*

PX225D*

PX124

PX224

ExCal Model

-

-

-

PX124/E

PX224/E

Approved Model**

PX125DM*

PX85M*

PX225DM*

PX124M

PX224M

Verification Interval (e) (g)

0,001

Class (Approved Models)

I

Capacity (g)

52/120

82

82/220

120

220

Readability d, Fine Range (g)

0.00001

-

Readability d, Full Range (g)

0.0001

0.00001

0.0001

0.0001

Repeatability (sd.),

≤5% of Full Load (g)

0.00001

0.00008

Repeatability (sd.), 5% of Full Load to Fine Range Max (g)

0.00002

-

Repeatability (sd. ), Fine Range Max to Full Range (g)

0.0001

0.00002

0.0001

0.0001

Linearity deviation, Typical (g)

± 0.00006

Linearity deviation (g)

± 0.0001

± 0.0002

Stabilization Time (s)

10

3

Sensitivity Temperature Drift (PPM/K)

± 0,8

± 3

Min-Weight (typical) (USP, K=2, U=0.10%)

20 mg

160 mg

Min-Weight (optimal)

(USP, K=2, U=0.10%, SRP≤0.41d)***

8.2 mg

82 mg

Units

Milligram, Gram, Kilogram, Ounce, Pound, Carat, Pennyweight, Ounce Troy, Grain, Newton, Hong Kong Tael, Singapore Tael, Taiwan Tael, Momme, Tical (MM), Mesghal, Tola (India), Baht, 1 Custom unit

Units (Approved Models)

g, mg, ct

Applications

Basic Weighing, Parts Counting, Percent Weighing, Animal Weighing, Density Determination

Pan Size (Ø)

80 mm

90 mm

Power Supply

Power Input: 100 – 240V ~ 200mA 50 – 60Hz 12 –18VA

Power Output: 12 VDC 0,5A

Assembled Dimensions (W × D × H)

209 × 321 × 309 mm

Communication

RS232 and USB

Operating Temperature Range

Operating conditions for ordinary lab application: +10°C to 30°C (operability guaranteed between +5°C and 40°C).

Net Weight

4,5 kg

Shipping Weight

7 kg

Shipping Dimensions (W × D × H)

507 × 387 × 531 mm
