Accessories required to connect to the AD-8526 |
Weighing instrument | Interface option for the instrument | Communication cable (2 m) |
GX, GF, GX-K, GF-K, GP, FP AD-4212A, AD-4212B, GR, HR | None (D-sub 25-pin, standard accessory) | AX-KO1710-200 |
EK-i, EW-i, FC-i, FC-Si, HR-i | None (D-sub 9-pin, standard accessory) | AX-KO2466-200 |
EK-G, EK-H, ET-W, EW-G | OP-03 (D-sub 25-pin) | AX-KO1710-200 |
HV-G, HV-WP, HW-G, HW-WP, HW-G | None (Din 7-pin, standard accessory) | AX-KO1786-200 |
FG, HC-i | OP-03 (Din 7-pin) | AX-KO1786-200 |
FS, FS-KL | OP-03 (Din 8-pin) | AX-KO1786-200 |
FG-L, FG-M | OP-23 (Din 8-pin) | AX-KO1786-200 |
AD-4322A | OP-04 (D-sub 25-pin) | AX-KO1710-200 |
AD-4405 | None (D-sub 9-pin) | AX-KO2466-200 |
AD-4410 | None (D-sub 9-pin, standard accessory) | AX-KO2466-200 |
Please use the Ethernet interface option GH-08 for the GH Series, FXi-08 for the FZ-i / FX-i, FZ-iWP / FX-iWP, and FZ-CT / FX-CT Series, and AD-4212A-08 for the AD-4212A / AD-4212B Series. |
