2mag 66306 HOTPLATE 6 Multi-Position Hotplate Magnetic Stirrer with heatMIXcontrol
ZoomCreated with Sketch.

2mag Multi-Position Hotplate Magnetic Stirrer with heatMIXcontrol

Score: 5.00 (votes: 1)
No reviews.
2mag AG

The 2mag Multi-Position Hotplate Magnetic Stirrer with heatMIXcontrol is a versatile laboratory instrument designed for simultaneous stirring and heating in multiple positions. This device combines the functions of a magnetic stirrer and a hotplate, making it ideal for various laboratory applications where precise temperature control and mixing are required.

SKU Number of Positions Stirring Positions Distance (mm) Models Stirring Volume / Stirring Point Speed Range (rpm) Temperature Range Weight (In Grams) Price (excluding VAT) Availability Qty To Purchase
2mag 66306 HOTPLATE 6 Multi-Position Hotplate Magnetic Stirrer with heatMIXcontrol 66306 6 130 HOTPLATE 6 1 - 1500ml 100 - 2,000 +40 °C up to +200 °C 13000 £7039.50 1 + -
2mag 66315 HOTPLATE 15 Multi-Position Hotplate Magnetic Stirrer with heatMIXcontrol 66315 15 65 HOTPLATE 15 1 - 1,000 ml 100 - 2,000 +40 °C up to +200 °C 13000 £7528.75 1 + -

Developed for stirring and temperating jobs in daily lab use and uncompromising continuous operation.

Specifications

Type HOTPLATE 6 HOTPLATE 15
Stirring positions 6 15
Stirring positions distance 130 mm 65 mm
Stirring volume / stirring point 1 - 1,500 ml 1 - 1,000 ml
Stirring power (max.) 40 W
Power setting 10 - 100% (10-step)
Temperature range +40 °C up to +200 °C
Speed range 100 - 2,000 rpm
Operating voltage 230 V
Heating power (max.) at 230 V 1,200 W
Dimensions (WxDxH) 250 x 430 x 75 mm
Protection category IP20
Weight (gross) approx. 13.0 kg
Order no. 66306 66315

2mag stirring-heating plate combination with 6 stirring positions, incl. control unit heatMIXcontrol, universally applicable for miscellaneous vessel sizes and shapes, stirring point distance 130 mm, suitable for 6 x 1,000 ml Erlenmeyer flasks.

Stirring - Powerful 6 stirring points, maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept, extremely wide speed range of 100 to 2,000 rpm, 100% synchronized speed, jerk-free stirring even at low speeds, 10-step power settings of the stirrer, high power setting for viscous liquids and reduced power setting for long-term operation without any heating effects caused by the stirrer, clear digital display for settings of stirrer speed, stirrer power and temperature of the integrated heater, SoftStart procedure for reliable catching/centering and safe acceleration of the stirring bar.

Heating - Heating plate made of resistant aluminium alloy, PTFE-coated for increased chemical resistance and easier cleaning, fast heating-up by powerful integrated electrical heater, homogenous temperature distribution, maximum heating temperature +200 °C, PowerDetect for automatic compensation of physically determined loss in stirring power which can come up to 40% at high temperatures, independent over-temperature protection inside the plate.

Inclusive separate control unit for operation of magnetic stirrer and integrated heater, for long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, stainless steel housing.

  •  Strirring-heating plate with 6 positions
  •  Stirring point distance 130 mm
  •  Stirring speed from 100 up to 2.000 rpm
  • Fast heating-up up to 200°C
  • Energy-saving
  • For all vessel sizes and shapes
  •  Simple system integration
  • 3 years warranty
  •   Developed and made in Germany


Delivery contents:

  • STIRRING HOTPLATE 6
  • Control unit heatMIXcontrol
2mag stirring-heating plate combination with 15 stirring positions, incl. control unit heatMIXcontrol, universally applicable for miscellaneous vessel sizes and shapes, stirring point distance 65 mm, suitable for 15 x 250 ml beaker glasses (tall form).

Stirring - Powerful 15 stirring points, maintenance-free and wear-free by inductive 2mag-Magnetic-Drive concept, extremely wide speed range of 100 to 2,000 rpm, 100% synchronized speed, jerk-free stirring even at low speeds, 10-step power settings of the stirrer, high power setting for viscous liquids and reduced power setting for long-term operation without any heating effects caused by the stirrer, clear digital display for settings of stirrer speed, stirrer power and temperature of the integrated heater, SoftStart procedure for reliable catching/centering and safe acceleration of the stirring bar.

Heating - Heating plate made of resistant aluminium alloy, PTFE-coated for increased chemical resistance and easier cleaning, fast heating-up by powerful integrated electrical heater, homogenous temperature distribution, maximum heating temperature +200 °C, PowerDetect for automatic compensation of physically determined loss in stirring power which can come up to 40% at high temperatures, independent over-temperature protection inside the plate.

Inclusive separate control unit for operation of magnetic stirrer and integrated heater, for long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, stainless steel housing.

  • Strirring-heating plate with 15 positions
  • Stirring point distance 65 mm
  • Stirring speed from 100 up to 2.000 rpm
  • Fast heating-up up to 200°C
  • Energy-saving
  • For all vessel sizes and shapes
  • Simple system integration
  • 3 years warranty
  • Developed and made in Germany

Delivery contents:

  • STIRRING HOTPLATE 15
  • Control unit heatMIXcontrol



Separate Control Unit Heatmixcontrol For Operation Of 2Mag Stirring Drybath And Stirring Hotplate.

Long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, independent and adjustable over-temperature limiter for the additional protection of the heating controller against technical defects or unintended operation errors, stainless steel housing, compact and space-saving, connection for external Pt100 sensor, RS232 interface.

    • Weight (In Grams)
      13000 g
    • SKU
      66306
    • Commodity Codes
      84798200
  • Manufacturer
    2mag AG
  • Country of Origin
    Germany
  • Number of Positions
    6, 15
  • Stirring Positions Distance (mm)
    130, 65
  • Models
    HOTPLATE 6, HOTPLATE 15
  • Stirring Volume / Stirring Point
    1 - 1500ml, 1 - 1,000 ml
  • Speed Range (rpm)
    100 - 2,000, Not Applicable
  • Temperature Range
    +40 °C up to +200 °C, Not Applicable
