Bigneat is a Leader in Carbon Filtration Technology
High-performance laboratory-grade carbon filter media is impregnated with additives to ensure the best possible retention capacities and filtration performance. Bigneat was one of the first companies to replace potentially toxic and carcinogenic inorganic additives with environmentally friendly and biodegradable compounds whilst maintaining excellent performance.
Bigneat’s carbon media have excellent retention capacities which are amongst the best in the world. Our programme of research and development continues to improve filter performance.
- Excellent filter casing design
- Only the highest grade of carbon is used, sourced carefully and monitored for changes in its grade
- Good cabinet design ensures an even airflow through the filter
Particulate HEPA Filtration
Pre-filtration eliminates particles at 5.0 microns or larger to an efficiency of 92% as defined in BS EN ISO 779.
HEPA filtration (H14 Standard) eliminates particles 0.3 microns or larger to the efficiency of 99.995%.
ULPA (U16 Standard) is available as an optional upgrade and has an efficiency of 99.999% for particle sizes of 0.1 – 0.3 microns MPPS (Most Penetrating Particle Size) as defined in EN 1822.
Choosing your optimised Chemcap™ filtration with or without particulate filtration.
Filters OS and H+ are suitable for most organic vapours and acid handlings. | Composition of vapours handled | Filter type 2-stage without particulates | Filter Type 3-stage for chemicals with particulates (HEPA) |
---|---|---|---|
Organic Compounds predominate | ORGANIC VAPOURS secondary acids | Filter OS | Filter OS HP + |
Acid compounds predominate | ACID VAPOURS secondary organic vapours | Filter H+ | Filter H+ HP |
Formaldehyde predominates | FORMALDEHYDE | Filter F | Filter F HP |
Ammonia predominates | AMMONIA | Filter AM | Filter AM HP |
Radioactive particles are present | RADIOACTIVE IODINE | -- | Filter Ri HP |
Mercury is present | MERCURY | -- | Filter Hg HP |
Uses are varied | MULTIPURPOSE | Filter MP | Filter MP HP |
Carbon Filtration
Chemcap™ filters are used in all Bigneat cabinets and provide a filtration efficiency of 99.9% for the duration of the filter life, with no deterioration in filter performance. Chemcap™ filters have been developed following years of research and are manufactured to maximise both the chemical adsorption and physical absorption characteristics of carbon to achieve this high level of filtration performance.
