Daicel 85522 CHIRALPAK ® IE-3 Analytical HPLC Chiral Column, Polysaccharide Derivatives Solvent-based Chiral Columns 4.6mm, 50mm, 3µm

Not rated yet
Free Mainland UK Shipping


The surface of the silica was covalently bound with amylose - tris (3,5-dichlorophenylcarbamate)

IE solvent-resistant chiral column, the amylose-tris (3,5-dichlorophenylcarbamate) covalently bonded to the surface of the silica gel.

Unrestricted use of solvents, a wide range of dissolution conditions, the use of any miscible solvent as a mobile phase, dissolved samples, chiral column regeneration.

Examples of solvents that can be used:

Normal phase: n-Hexane, IPA, EtOH

Special mobile phase: Ethyl acetate, CH 3 Cl, THF, MTBE

Inverted: H 2 O, of IPA, MeOH

  • £1050.00
In Stock:

Parameters

Filler particle sizeCHIRALPAK ® IE-3: 3μm
CHIRALPAK ® IE: 5μm
pressureIn order to extend the service life of the chiral column, it is recommended to keep the pressure below 30MPa
pH valuepH 2.0 ~ 9.0
temperature0 ~ 40 ℃
Save the solventCHIRALPAK ® IE-3: n-Hexane / 2-Propanol = 90/10 (v / v)
CHIRALPAK ® IE: n-Hexane / Ethanol = 90/10 (v / v)


Column Storage

For column storage, remove the acidic or basic additives by flushing the column with the same mobile phase without the additive. Columns can be stored with the additive-free mobile phases.

Operating these columns in accordance with the guidelines outlined here will result in a long column life.

Mobile phase

i CHIRAL serise series can use various types of solvents as the mobile phase or dissolve the sample solvent (note the mutual solubility between solvents), for example as follows:

  N-Hexane

  Dimethylsulfoxide (DMSO)

  Isopropanol (IPA)

  ● Chloroform (Trichloromethane)

  ● Methyl tert-butyl ether (MTBE)

  ● Methyl cyanide

  ● Dichloromethane

  ● Methylbenzene

  Tetrahydrofuran (THF)

  1,4-Dioxane

  ● Acetic ether

  Water (H 2 O)


    • SKU
      85522
    • Commodity Codes
      90279050
  • Manufacturer
    Chiral Technnologies (Part of Daicel Group)
  • Country of Origin
    Japan
  • Chromatography HPLC or GC
    • Particle size (µm)
      3
    • Internal Diameter (mm)
      4.6
    • Length (mm)
      50
    • Temperature range (°C)
      0 ~ 40 ℃
    • pH Range
      2-9
    • Packing Phase
      CHIRALPAK ® IE-3
