Binder Series BD Avantgarde.Line Standard Incubators

Score: 5.00 (votes: 1)
No reviews.
authoriseddistributor.png ezgif-2-bbd2100077_e4ca16fae1ae75348ca4916c5e80a7b7.png



The Binder BD Avantgarde.Line Standard Incubators are high-performance microbiological incubators designed to offer precise temperature control and an efficient, reliable environment for the cultivation and growth of microorganisms. These incubators are part of Binder's Avantgarde.Line, which is known for advanced technology, quality, and energy efficiency.

SKU Interior Volume [L] Internal Dimensions (mm) Model Rated Voltage Temperature Range (Metric) Circulation Weight (In Grams) Price (excluding VAT) Availability Qty To Purchase
9010-0323 9010-0323 57 380 x 420 x 360 BD056-230V 230 V 1~ 50/60 Hz +5°C Above Ambient Temperature To +100°C Natural Convection 39000
£1518.00
£1221.99
51 + -
9010-0325 9010-0325 112 420 x 530 x 510 BD115-230V 230 V 1~ 50/60 Hz +5°C Above Ambient Temperature To +100°C Natural Convection 54000
£2044.00
£1788.50
20 + -
9010-0329 9010-0329 253 760 x 940 x 810 BD260-230V 230 V 1~ 50/60 Hz +5°C Above Ambient Temperature To +100°C Natural Convection 85000
£3461.00
£2786.11
22 + -
9010-0331 9010-0331 737 870 x 1590 x 1165 BD720-230V 230 V 1~ 50/60 Hz +5°C Above Ambient Temperature To +100°C Natural Convection 169000
£6732.00
£5890.50
11 + -

The completely redesigned Avantgarde.Line incubators with gravity convection or forced convection are now the perfect solution when it comes to meeting growth and incubation requirements. With their exceptional efficiency and perfect temperature accuracy thanks to the very latest APT.line™ technology, this new generation of incubators has real appeal.

Series BD Avantgarde.Line | Standard-Incubators with natural convection

The BD Avantgarde.Line series is specially designed for gentle incubation of organisms, as well as conditioning of heat-sensitive media. The new design of the units and the homogeneous temperature distribution ensure the very best results.

Incubator with natural convection from BINDER

If you are looking for stable incubation processes guaranteed, you need look no further than incubators from BINDER. Series BD incubators function with natural convection and, thanks to their state-of-the-art technical equipment, are a reliable choice for the incubation of microbiological cultures.

This BINDER incubator with natural convection comes in a range of versions and sizes. Operating within a temperature range of between 5 °C and 100 °C, they are equipped with the proven APT.line™ preheating chamber technology and an adjustable exhaust air flap. The inner door is made from tempered safety glass, guaranteeing a stable atmosphere.

Incubator with natural convection for optimum, reproducible results

This BINDER incubator with natural convection is really easy to use thanks to the controller with timer functions and the visual temperature alarm. The units can be stacked on top of one another for an optimum ratio between stand space and usable space.

Plus, compared to similar incubators, the units from BINDER boast high levels of temperature accuracy, excellent usability, and options for ease of cleaning. The incubator with natural convection guarantees results that are reproducible at any time, with uniform incubation conditions even under high batch throughputs in long-term operation. These incubators are ideal for all incubation processes within the fields of research, production, and quality assurance.

Benefits

  • Excellent temporal and spatial temperature accuracy
  • High process reliability
  • 100 °C disinfection routine

Important characteristics

  • Temperature range: ambient temperature plus 5 °C to 100 °C
  • High temperature accuracy thanks to APT.line™ technology
  • Gravity convection
  • Controller with LCD display
  • Electromechanical control of the exhaust air flap
  • Inner door made of tempered safety glass
  • 2 chrome-plated racks
  • Units up to 115 L are stackable
  • Class 3.1 integrated independent temperature safety device (DIN 12880) with visual alarm
  • Ergonomic handle design
  • USB port for recording data



Techanical Data


Model

BD 56

BD 115

BD 260

BD 720

Temperature range

+5 °C above ambient temperature to 100 °C

+5 °C above ambient temperature to 100 °C

+5 °C above ambient temperature to 100 °C

+5 °C above ambient temperature to 100 °C

Temperature uniformity at 37°C

0.3 ± K

0.3 ± K

0.3 ± K

0.7 ± K

Temperature uniformity at 100°C

1.1 ± K

1.0 ± K

1.0 ± K

3.0 ± K

Temperature fluctuation at 37°C

0.1 ± K

0.1 ± K

0.2 ± K

0.1 ± K

Temperature fluctuation at 100°C

0.3 ± K

0.3 ± K

0.5 ± K

0.3 ± K

Heating up time to 37°C

52 min

55 min

60 min

70 min

Heating up time to 100°C

75 min

90 min

75 min

90 min

Recovery time after door was opened for 30 s at 37°C

15 min

15 min

16 min

23 min

Permitted load

70 kg

150 kg

270 kg

315 kg

Load per rack

30 kg

30 kg

40 kg

45 kg

Net weight of the unit (empty)

39 kg

54 kg

85 kg

169 kg

Width net

560 mm

710 mm

810 mm

1,165 mm

Height net

625 mm

705 mm

940 mm

1,590 mm

Depth net

565 mm

605 mm

760 mm

870 mm

Width gross including packing

640 mm

790 mm

900 mm

1,250 mm

Height gross including packing

840 mm

950 mm

1,170 mm

1,820 mm

Depth gross inclusive packing

790 mm

720 mm

885 mm

950 mm

inner space width

360 mm

510 mm

610 mm

960 mm

inner space height

420 mm

530 mm

760 mm

1,280 mm

inner space deep

380 mm

420 mm

545 mm

600 mm

Wall clearance back

160 mm

160 mm

160 mm

160 mm

Wall clearance sidewise

100 mm

100 mm

100 mm

100 mm

Power frequency

50/60 Hz

50/60 Hz

50/60 Hz

50/60 Hz

Nominal power

0,3 kW

0,35 kW

0,85 kW

1,65 kW

Unit fuse

6,3 A

6,3 A

8,0 A

16,0 A

Phase (Nominal voltage)

1~

1~

1~

1~

Energy consumption at 37°C

25 Wh/h

25 Wh/h

40 Wh/h

78 Wh/h

Energy consumption at 100°C

110 Wh/h

150 Wh/h

225 Wh/h

480 Wh/h

Interior volume

57

112

253

737

Convection type

Natural convection

Natural convection

Natural convection

Natural convection

Humidity

no

no

no

no

Interfaces

USB

USB

USB

USB

Data recording

APT-COM software || USB

APT-COM software || USB

APT-COM software || USB

APT-COM software || USB



    • Weight (In Grams)
      39000 g
    • SKU
      9010-0323
    • Commodity Codes
      90278990
  • Manufacturer
    BINDER GmbH
  • Country of Origin
    Germany
  • Interior Volume [L]
    57, 112, 253, 737
  • Internal Dimensions (mm)
    380 x 420 x 360, 420 x 530 x 510, 760 x 940 x 810, 870 x 1590 x 1165
  • Model
    BD056-230V, BD115-230V, BD260-230V, BD720-230V
  • Rated Voltage
    230 V 1~ 50/60 Hz, 240 V 1~ 50/60 Hz
  • Temperature Range (Metric)
    +5°C Above Ambient Temperature To +100°C, Not Applicable
  • Circulation
    Natural Convection, Not Applicable
